Heat Generating Paints

Innovative thermal management with graphene technology.

Our cutting-edge heating paints, developed with graphene, provide advanced thermal management solutions for both industrial and residential applications.

How does it work?

Below a real world example

The application of a low voltage to the graphene paint determines an electrical current generating heat. Thanks to graphene outstanding electrical and thermal conductivity, the heat is evenly distributed all across the surface of the paint, providing a comfortable and uniform heating experience.

Heating curve vs time

Image of heating painted substrate

Application performances

Electrodes distance

80 cm

Voltage

33 V

Electrodes length

25 cm

Current

2.81 A

Number of hands

3

Power

92.7 W

Yielde

7 m2 /Kg

Specific power

463.7 W/m2

Resistance

11.9 Ohm

Average T

45°C

Application performances

The following performances have been obtained in test cases for different kinds of paints.

Paint type

Thickness [microns]

Breakdown Voltage [kV]

Dielectric Strenght [kV/mm]

Acrylic

100

6

60

Epoxy

60 – 200

3,3 – 10

55 – 49,5

Phenolic

50 – 190

2,5 – 3,1

48 – 16,5

Application performances

The following performances have been obtained in test cases for different kinds of paints.

Paint type

Acrylic

Thickness [microns]

100

Breakdown Voltage [kV]

6

Dielectric Strenght [kV/mm]

60

Paint type

Epoxy

Thickness [microns]

60 – 200

Breakdown Voltage [kV]

3,3 – 10

Dielectric Strenght [kV/mm]

55 – 49,5

Paint type

Phenolic

Thickness [microns]

50 – 190

Breakdown Voltage [kV]

2,5 – 3,1

Dielectric Strenght [kV/mm]

48 – 16,5

Applications

Key Features and Benefits
